The AluFrames Pocket Vetro is a hidden aluminium sliding system designed for glass pocket doors, offering a seamless, sophisticated look without a visible counterframe. It is compatible with Vetro 24 and Vetro 40 clamp systems, suitable for glass thicknesses of 8–8.7 mm, 10–10.7 mm, and 12–12.7 mm. Supporting up to 80 kg, AluFrames Pocket Vetro ensures smooth, quiet operation with its innovative Push Magnetic soft-closing system. Ideal for premium interior designs where transparency and minimalism are key.
Key Features:
-
Concealed sliding track system for glass pocket doors
-
Supports glass panels up to 80 kg
-
Compatible with Vetro 24 and Vetro 40 clamp systems
-
Works with glass thicknesses: 8–8.7 mm, 10–10.7 mm, 12–12.7 mm
-
Easy maintenance access with no wall damage
-
Integrated Push Magnetic system for soft and easy opening/closing
-
Track finishes available: Mill Finish, Anodized Silver, Anodized Black
-
Maximum glass door width: 1250 mm | Maximum door height: 2200 mm
| Door Material | Glass |
|---|---|
| Max Door Weight | 80 kg |
| Max Door Width | 1250 mm (49.2") |
| Max Door Height | 2200 mm (86.6") |
| Min Door Width | 600 mm (23.6") |
| Track Type | Concealed aluminium rail (for pocket doors) |
| Compatible Systems | Vetro 24 (24 mm clamps) / Vetro 40 (40 mm clamps) |
| Soft Close System | Integrated Push Magnetic + Fluid Damper |
| Door Removal | Easy (without breaking plasterboard) |
| Track Finishes | Mill Finish, Anodized Silver, Anodized Black |
| Glass Thickness Supported | 8–8.7 mm (5/16"), 10–10.7 mm (3/8"), 12–12.7 mm (1/2") |
| Available Track Lengths | 2500 mm (98.4") standard (optionally 2000 mm (78.7") or 3000 mm (118.1") on request) |
